Kingspan and Austech are in partnership to customise insulation products to your needs. GreenGuard® and Kooltherm® are premium performance products with a fibre-free rigid thermoset phenolic core, faced on both sides with a low emissivity composite foil.
Kingspan insulation is a market-leading manufacturer of innovative ultra-thin flexible insulation products and high-performance rigid insulation products for building fabric and building services applications. Kingspan Insulation is committed to providing the world market with high quality, innovative products supported by technical expertise and customer service which is unsurpassed in the industry.
Kingspan Insulation has a vast product range including premium performance rigid Kooltherm® insulation; high performance rigid Therma™ insulation and flexible fibre-free reflective insulation AIR-CELL®.
Low Energy – Low Carbon Building

Insulation assists in the prevention of heat movement through all elements of your building envelope. Using a continuous layer of insulation will help manage the effects of thermal bridging, such as heat loss and heat gain.
While insulation might not be the first thing that comes to mind when thinking about a comfortable building, it might arguably be the most important.

Kingspan Kooltherm® products help correctly insulate your building envelope and limit reliance on active heat and cooling.
Kingspan Insulation’s AIR-CELL was the first insulation product in Australia to certify to the National Construction Code under the CodeMark scheme, beating the rest of the industry including the region’s largest manufacturers to the mark.

GreenGuard GG300, GG500, GG700

Resistance to solvents, fungi & rodents

Kingspan GreenGuard® is resistant to most commonly occuring construction materials such as lime, cement, plaster, anhydrous gypsum, solvent-free bituminous compounds, water-based wood preservatives, as well as alcohols, acids and alkalis. Certain organic materials such as solvent-based preservatives, coal tar and derivatives (creosote), paint thinners and common solvents (e.g. acetone, ethyl acetate, petrol, toluene and white spirit) will attack Kingspan GreenGuard®, resulting in softening, shrinkage and possible dissolution, with a consequent loss of performance.

  • High performance rigid extruded polystyrene insulation
  • Protects waterproofing membrane
  • Minimal water absorption
  • High compressive strength
  • Withstands freeze/thaw cycling
  • Compatible with green roof systems n Resistant to the passage of water vapour
  • Easy to handle and install
  • Ideal for new build and refurbishment
  • Non–deleterious material
  • Manufactured with a blowing agent that has zero ODP

K3 Floorboard

Insulation for solid concrete ground-based floors

Kingspan Kooltherm K3 Floorboard is a high performance, fibre-free rigid thermoset closed cell phenolic insulation core, sandwiched between two layers of tissue-based facing autohesively bonded to the insulation core during manufacture.

Kingspan Kooltherm K3 Floorboard is manufactured without the use of CFCs/HCFCs and has zero Ozone Depleting Potential (ODP) and low Global Warming Potential (GWP).

  • High-performance rigid thermoset
    phenolic insulation
  • Fibre-free, closed-cell insulation core
  • Resistant to the passage of water vapour
  • Easy to handle and install
  • Ideal for new build and refurbishment
  • No CFC or HCFC is used in the manufacture
  • Has zero ODP and low GWP
  • NCC and AS/NZS 4859.1:2018 compliant
  • Made in Australia

K8 Cavity Board

Partial fill cavity wall insulation

Cavity Board is a super high performance, fibre-free rigid thermoset closed cell phenolic insulation core, sandwiched between two layers of reflective, low emissivity composite foil autohesively bonded to the insulation core during manufacture. This reflective, low emissivity surface improves the thermal resistance of any cavity adjacent to the board.

  • Super high-performance rigid thermoset phenolic insulation
  • Fibre-free, closed-cell insulation core
  • Clear cavity is maintained – resists moisture penetration
  • Low emissivity foil facings significantly increase the thermal resistance of the cavity
  • Easy to handle and install
  • No CFC or HCFC used in the manufacture
  • Has zero ODP and low GWP
  • Compliant with AS/NZS 4859.1:2018
  • CodeMark-certified for NCC compliance
  • Made in Australia

K10 & K10 Plus Soffit Board Group 1 and 2 (G1-G2)

Insulation for structural ceilings

  • High-performance rigid thermoset phenolic insulation (G1)
  • Fibre-free, closed-cell insulation core (G1)
  • FM approved to Class 1 fire rating Class Number 4880 (G1)
  • Resistant to the passage of water vapour (G1)
  • Easy to handle and install (G1) Ideal for new build and refurbishment (G1)
  • Rodent, mould and fungi resistant (G1)
  • Manufactured with a CFC/ HCFC-free blowing agent that has zero ODP and low GWP (G1)
  • Compliant with AS/NZS 4859.1/ Amdt 1/2006
  • ISO 9001 Quality Standards (G1)
  • High-performance rigid thermoset phenolic insulation (G2)
  • Fibre-free, closed-cell insulation core (G2)
  • FM approved to Class 1 fire rating Class Number 4880 (G2)
  • Group 2 NCC fire classification determined in a full room ISO 9705 test in accordance with AS/NZS 5637 (G2)
  • Resistant to the passage of water vapour (G2)
  • No CFC or HCFC used in manufacture (G2)
  • Has zero ODP and low GWP (G2)
  • NCC and AS/NZS 4859.1:2018 (G2)
  • Made in Australia (G2)
  • CodeMark-certified for NCC compliance (G2)

K17 Plasterboard

Insulated Dry-Lining plasterboard for adhesive bonding

  • Super high-performance rigid thermoset phenolic insulation
  • Fibre-free closed cell insulation core 3-in-1 insulation, dry-lining and vapour control
  • Also available in a range of other selected lining materials
  • Group 1 BCA fire classification
  • Allows quick response heating and cooling
  • Resistant to the passage of water vapour
  • Easy to handle and install
  • Ideal for new build and refurbishment
  • Manufactured with a CFC/ HCFC-free blowing
    agent that has Zero ODP and low GWP
  • Compliant with AS/NZS 4859.1
  • ISO 9001 Quality Standards

10 Years Warranty

Kooltherm®
Kingspan
 hereby confirms that the aforementioned rigid Kingspan Kooltherm® insulation products are manufactured to ISO 9001 quality standards in accordance with the company’s product specification schedule and in compliance with the Insulation Materials Standard AS/NZS 4859.1.

GreenGuard®
GreenGuard® insulation products are manufactured to ISO 9001quality standards in accordance with the company’s product specification schedule and in compliance with the Insulation Materials Standard AS/NZS 4859.1.

Download full Conditions of Warranty

Email us with your project plans, so we can guide you through our collection of technical data, scientific journals and manuals.
We will send you a link to download all the files you need.
